Continue with the current browserCustomized planning and engineering support for your system
The configuration of power distribution and automation elements when designing water and wastewater systems, pump stations, and desalination plants determine their reliability, cost efficiency, and performance. To give consultant engineers and planners the best possible assistance with this task, Siemens has developed an efficient tool for your day-to-day work: the Siemens Water Portal. The portal contains all information relevant to the planning process in terms of electrotechnical equipment, along with practical examples for configuring the automation and power distribution.
With the Industry
Online Support you have access to more
than 300,000 documents about Siemens Industry products.
What's New?
We constantly work on improving and expanding the Water Portal to offer our best support to you. To make the updates more visible we will post our latest and upcoming changes below.
Sample Configurations
Desalination
Desalinate Seawater – Preserve Life
As a planner and operator, the most important aspects of seawater desalination are improving security of supply, reducing energy requirements, and ensuring the highest level of water treatment control. Due to the complex nature of the plants, state-of-the-art control and monitoring systems are indispensable. After all, the process not only uses a great deal of energy, it is also expensive.
We offer a wide range of application examples to further improve the efficiency of your system configuration. These make all the difference when it comes to planning more quickly, efficiently, and reliably – and you will benefit from maximum transparency at all times to allow you to make an informed decision regarding product selection.
Here you will find a scalable automation and drive technology concept based on a medium seawater desalination plant supplying 14,000 m³/day. When it comes to the specific configuration of your station, we support you with our extensive portfolio of products, services, and templates for SIMATIC PCS 7 – from design to operation and maintenance.
Desalination Medium (14,000 m³/day - PCS 7)
Here you will find a scalable automation and drive technology concept based on a large seawater desalination plant supplying 200,000 m³/day. When it comes to the specific configuration of your station, we support you with our extensive portfolio of products, services, and templates for SIMATIC PCS 7 – from design to operation and maintenance.
Desalination Large (200,000 m³/day - PCS 7)Water Treatment
Ensuring a Lasting Water Supply
In many regions of the world, groundwater is not enough to cover the need for drinking water. As a result, water treatment using surface water or even waste water become increasingly important, especially in countries that face constant water shortages or whose flowing water is heavily polluted. With our intelligent automation technology, drive technology, switch technology, and power distribution systems we support you as a planner and operator in ensuring that your plant runs smoothly and that drinking water treatment can continue day after day.
We have many different application examples to help make your system configuration even more efficient. They make all the difference when it comes to planning more quickly, efficiently, and reliably – and you will benefit from maximum transparency at all times to ensure a reliable product selection.
Typical configurations for water utilities are classified according to the daily throughput volume. Medium-sized facilities with a volume of about 5,000 cubic meters per day are best suited to smaller communities and towns. When configuring your water utility, we provide an extensive portfolio of products, services, and templates that cover all stages, from design to operation and maintenance.
Water Treatment Medium (5,000 m³/day - WinCC)
Typical configurations for water treatment plants are classified according to the daily throughput volume. Large facilities with a volume of about 120,000 to 150,000 cubic meters per day are best suited to major metropolitan areas. When configuring your water treatment plant, we provide an extensive portfolio of products, services, and templates that cover all stages, from design to operation and maintenance.
Water Treatment Large (150,000 m³/day - PCS 7)Water Pump Station
Operating Water Supply Stations Efficiently
Pump stations play an extremely important role in the water supply. They convey water and feed it into the drinking water supply network. Because the pump stations and treatment plants are frequently separated by large distances, they are often unmanned. With our comprehensive portfolio, we support you as a system planner, equipment supplier, and plant operator by means of end-to-end engineering as well as consistent and reliable process management, both for central and remote sub-plants. For the latter we offer secure integration via telecontrol technology, with central as well as on-site or emergency operating level, and we thus ensure availability and security of supply.
We have many different application examples to help make your system configuration even more efficient. They make all the difference when it comes to planning more quickly, efficiently, and reliably – and you will benefit from maximum transparency at all times to ensure a reliable product selection.
Here you will find a scalable automation and drive technology concept based on the example of a very large water pump station. When it comes to the concrete configuration of your station, we support you with an extensive portfolio of products, services, and templates, from design to operation and maintenance.
Water Pump Station Very Large (360,000 m³/day - PCS 7)Wastewater Pump Station
Operating Wastewater Pump Stations Efficiently
Pump stations play an extremely important role in the disposal of water. They pump waste water to treatment plants via the wastewater network. Because the pump stations and treatment plants are frequently separated by large distances, they are often unmanned. With our comprehensive portfolio, we support you as a system planner, equipment supplier, and plant operator by means of end-to-end engineering as well as consistent and reliable process management, both for central and remote sub-plants. For the latter we offer secure integration via telecontrol technology, with central as well as on-site or emergency operating level. Preconfigured automation solutions are available especially for the transport of wastewater; these solutions independently detect and correct issues such as incipient pump blockages.
We have many different application examples to help make your system configuration even more efficient. They make all the difference when it comes to planning more quickly, efficiently, and reliably – and you will benefit from maximum transparency at all times to ensure a reliable product selection.
Here you will find a scalable automation and drive technology concept based on the example of a very large wastewater pump station. When it comes to the specific configuration of your station, we support you with an extensive portfolio of products, services, and templates, from design to operation and maintenance.
Wastewater Pump Station Very Large (575,000 m³/day - WinCC)Wastewater Treatment
Efficient and Reliable Wastewater Treatment
Wastewater from households and industry contains varying levels of contamination, which may be chemical, biological, or with solid matter. That makes reprocessing of wastewater extremely costly. As a planner and operator, you face the challenge of designing and operating your plant economically and ensuring that it will remain viable into the future. We are happy to support you with our comprehensive portfolio and individual solutions.
We have many different application examples to help make your system configuration even more efficient. They make all the difference when it comes to planning more quickly, efficiently, and reliably – and you will benefit from maximum transparency at all times to ensure a reliable product selection.
Typical configurations for small wastewater treatment plants are divided into three main classes, depending on population size: size category 1 (less than 1,000 inhabitants), 2 (1,000-5,000 inhabitants), and 3 (5,000-10,000 inhabitants). When configuring your wastewater treatment plant, we support you with an extensive portfolio of products, services, and templates that cover all stages, from design to operation and maintenance.
Wastewater Treatment Small (5,000 m³/day - WinCC_Unified)
Medium-sized wastewater treatment plants are used mainly in cities and communities of up to 100,000 inhabitants. These are divided into two size categories: 4a for 10,000 to 50,000 inhabitants and 4b for populations greater than 50,000. When configuring your treatment plant, we support you with an extensive portfolio of products, services, and templates, from design to operation and maintenance.
Wastewater Treatment Medium (8,000 m³/day - PCS 7)
Very soon, two-thirds of the world’s population will live in cities – many in major metropolitan areas. Facilities in size category 5, which treat wastewater from more than 100,000 inhabitants, are subject to special requirements. When configuring your treatment plant, we support you with an extensive portfolio of products, services, and templates that cover all stages, from design to operation and maintenance.
Wastewater Treatment Large (30,000 m³/day - PCS 7)
